BN15-300X
15-inch neodymium bass guitar speaker
BN15-300X neodymium bass speakers have a lightweight magnet for increased portability and is purpose built to provide 300-watt power handling and a rich warm bass tone.
Specifications
15in
Diameter
4Ω
Rated impedance
96dB
Sensitivity
Nominal diameter
381mm / 15in
Power rating
300W
Rated impedance
4Ω
Sensitivity
96dB
Magnet type
Neodymium
Voice coil diameter
2.5in / 63.5mm
Voice coil material
Copper
Former material
Polyimide
Cone material
Kevlar loaded paper
Surround material
Cloth-sealed
Frequency range
42-3500Hz
Gap height (Hg)
8mm / 0.31in
VC winding height (Hvc)
16mm / 0.62in
Parameters
Sd
855.3cm2 / 132.57in2
Fs
57.8Hz
Mms
84.24g / 2.97oz
Qms
4.49
Qes
1.1
Qts
0.9
Re
3.19Ω
Vas
98.7l / 3.48ft3
BI
9.13Tm
Cms
0.09mm/N
Rms
6.42kg/s
Le (at 1kHz)
0.39mH
Xmax
4mm / 0.15in
Mounting Information
Cut-out diameter
351mm / 13.8in
Diameter
385mm / 15.2in
Mounting hole dimensions
9.2x6.2mm / 0.36x0.24in
Mounting hole PCD
369mm / 14.5in
Number of mounting holes
8
Chassis depth (inc gasket)
116mm / 4.56in
Magnet depth
37mm / 1.44in
Overall depth
152mm / 6in
Unit weight
2.3kg / 5.1lb
